? PG2418TB
RECOMMENDED SOLDERING CONDITIONS
This product should be soldered and mounted under the following recommended conditions. For soldering methods and
conditions other than those recommended below, contact your nearby sales office.
Soldering Method
Soldering Conditions
Condition Symbol
Infrared Reflow
Wave Soldering
Peak temperature (package surface temperature)
Time at peak temperature
Time at temperature of 220 ? C or higher
Preheating time at 120 to 180 ? C
Maximum number of reflow processes
Maximum chlorine content of rosin flux (% mass)
Peak temperature (molten solder temperature)
Time at peak temperature
: 260 ? C or below
: 10 seconds or less
: 60 seconds or less
: 120 ? 30 seconds
: 3 times
: 0.2%(Wt.) or below
: 260 ? C or below
: 10 seconds or less
IR260
WS260
Preheating temperature (package surface temperature) : 120 ? C or below
Maximum number of flow processes
: 1 time
Maximum chlorine content of rosin flux (% mass) : 0.2%(Wt.) or below
Partial Heating
Peak temperature (terminal temperature)
Soldering time (per side of device)
: 350 ? C or below
: 3 seconds or less
HS350
Maximum chlorine content of rosin flux (% mass) : 0.2%(Wt.) or below
CAUTION
Do not use different soldering methods together (except for partial heating).
R09DS0007EJ0100 Rev.1.00
Aug 24, 2010
Page 9 of 10
